Mitutoyo 126-906 Series 126 Screw Thread Micrometer, Interchangeable Tips, 5-6", with Anvil Set

The Mitutoyo screw thread micrometer uses optional V-Anvil and conical spindle inserts interchangeably to precisely measure pitch diameters of metric or unified screw threads. A ratchet-stop mechanism provides uniform pressure on a workpiece for precise, repeatable measurements.

Features:

• Optional interchangeable 60 degree and 55 degree V-Anvil and conical spindle inserts are precision ground hardened, high-grade steel
• Ratchet mechanism provides an audible click to ensure measurement is performed at a constant force
• Satin chrome finish on the sleeve and laser etched measurements on thimble for easier reading
• Frame has a baked enamel finish for durability and longer lifespan
• Includes a standard bar
• Supplied in fitted case
• Anvil-spindle tip 126-800 set included

For more information, please see Data Sheet
