Sensaphone FGD-0220 J Series Thermocouple 4-20mA Converter

The J Type Thermocouple / 4-20mA Converter can be used with any Sensaphone model that accepts a 4-20mA signal to measure temperatures that are beyond the Sensaphone's temperature sensing range. The converter allows monitoring of temperatures from -148° to 572°F. The Sensaphone will trigger an alarm when the temperature falls outside of the programmed high or low temperature limit.

Features:

• Measures temperature from -148° to 572°F | -100° to 300°C
• Accurate to 0.08%
• The sensor will put out an analog current scaled from 4 to 20mA corresponding to the measurement range of the sensor
• Screw Terminals and Plug-in Terminal Blocks Simplify Wiring and Maintenance
• C-UL-US Listed (Class I, Division 2, Groups A, B, C, D)
