Mitutoyo 1921A-10 Series 0 Dial Gauge, Lug Back, ANSI/AGD Type, Jewelled Bearing, 0.1", 0.001"

The compact design of the Mitutoyo Series 0 dial indicator provides use in tight, restricted spaces. The jeweled bearing has a high wear resistance, and the balanced scale makes this indicator ideal for comparing measurements to a master. The stem and spindle are constructed of hardened steel for better durability. The glare-free crystal has a scratch-resistant coating for clearer readings and better durability. A revolutionary offset spindle bushing design provides trouble-free stem clamping and a longer clamping range.

Features:

• Bezel diameter: 31 mm/1.22"
• Greater rigidity in the bearing plate reduces retracing error by up to 20%
• 4-Screw mounting increases impact resistance for better, longer accuracy
• No through screw hole on the frame provides better dust resistance
• Contact point is carbide tipped for lasting accuracy, durability
• The indicator is anti-magnetic to keep steel filings from collecting on the contact
• Crystal is glare-free with a scratch-resistant coating
• Measuring force: 0.3-1.8N
• Inch indicators meet ANSI/AGD standards
• Metric indicators meet JIS/ISO standards
