Kennametal 7034324 Indexable Drill Insert, Carbide, KC7140, TiN, TiCN and TiN Finish, 5.30 mm Inscribed Circle, 2.40 mm Thick

Features:

• Indexable Drill Insert: DFPR050203MSI KC7140, Carbide
• KC7140, TiN, TiCN & TiN Finish, 5.30 mm Inscribed Circle, 2.40 mm Thick, 0.30 mm Corner Radius, 8 deg Proprietary
• Composition: PVD TiCN/TiN coated medium-grain carbide with high toughness.
• Four true cutting edges for lowest cost per part.
• Inboard Insert with unique nose-profile for best positioning accuracy.

Application:

• Best suited for machining of steel and stainless steel. This exceptionally tough grade is perfectly suited for metastable machining conditions offering excellent tool life.
• Drilling
• Drilling: Inclined Entry
• Drilling: Inclined Exit
• Drilling: X-Offset
• Drilling: Stacked Plates
• Drilling: Convex
• Drilling: Blind
• Chain Drilling
• Drilling: Cross-Hole Drilling
• Drilling: Half-Cylindrical Drilling
• Drilling: Corner Drilling 45°
