Kennametal 7030446 Series DFPR Indexable Insert Drill, 1.4770" Max Dia, 5.7520" Max Depth, 4xD, 1.5000" Shank Dia

Features:

• Indexable Insert Drill: DFPR1438R4WB150, 1.4770" Max Dia, 5.7520" Max Depth, 4xD, 1.5000" Shank Dia
• Weldon Flat & Flange Shank, Uses DFPR 110406 & 120405 Inserts, Series DFPR
• Versatile indexable drill, covering many workpiece materials.
• For straight hole drilling, inclined entries and exits, interrupted cuts, and rough casted, forged or welded entry surfaces.
• Two eccentric positioned coolant channels for higher coolant volume, providing higher metal removal rates, tool-life, and productivity.
• Helical flutes for perfect chip evacuation.
• Drill body provides high stiffness, eliminating noise and vibrations, resulting in best-in-class hole size accuracy and hole quality.
• The X-offset feature enables diameter adjustment within the machine, and applications on lathe machines.

Application:

• Shank - Cylindrical with Flat
• Drilling
• Drilling: Inclined Entry
• Drilling: Inclined Exit
• Drilling: X-Offset
• Drilling: Stacked Plates
• Drilling: Convex
• Through Coolant: Radial: Indexable Drilling
• Drilling: Blind
• Chain Drilling
• Drilling: Cross-Hole Drilling
• Drilling: Half-Cylindrical Drilling
• Drilling: Corner Drilling 45°
