Kennametal 6754938 Series KOR5 Corner Radius End Mill, 1" Dia, 3" LOC, 0.0600" Radius, 5 Flute, Solid Carbide

Features:

• Corner Radius End Mill: 1" Dia, 3" LOC, 0.0600" Radius, 5 Flute, Solid Carbide
• 5-1/2" OAL, 1" Shank Dia, 35 deg Helix, Bright/Uncoated Finish, Single End, Series KOR5
• Carbide grade made from high-quality, micrograin materials for cutting all types of workpiece materials.
• Very high toughness ensures a controlled wear rate. The micrograin structure enables extremely sharp cutting edges.
• Designed for trochoidal milling with low radial engagement and full length of cut.
• With chip splitters for ideal chip evacuation.
• Proprietary flute form reduces vibrations and improves tool life.
• Helix angle tailored to minimize vibration and optimize tool life.
• Front end geometry designed for maximum tool life in helical and ramping operations.
• Safe-Lock for pull out protection.

Application:

• Trochoidal Milling
• Through Coolant - Solid End Mill
• Ramping: 4°
• Tool Dimensions: Flute Configuration: 5
• Helix Angle: 35°
• Corner Style: Corner Radius
• Corner Style: Square End
• Side Milling / Shoulder Milling: Roughing
• Side Milling / Shoulder Milling: Finishing
• SAFE-LOCK Shank
