Kennametal 6146890 Series 3CH-DKL Square End Mill, 2.50 mm Dia, 3.00 mm LOC, 3 Flute, Solid Carbide, 50.00 mm

Features:

• Square End Mill: 2.50 mm Dia, 3.00 mm LOC, 3 Flute, Solid Carbide
• 50.00 mm OAL, 6.00 mm Shank Dia, 30 deg Helix, TiAlN Finish, Single End, Series 3CH-DKL
• Coated carbide grade with PVD multilayer coating.
• KC633M is designed for dry milling most types of material, apart from the hardened variety.
• This grade is characterized by high hardness and wear resistance.
• It provides outstanding protection for solid carbide tools against cratering and abrasion.
• Solid carbide end mill with stepped parallel shank according to DIN 6527
• Solid carbide end mill with excellent cost-benefit ratio
• Eccentric relief increases cutting edge stability for long tool life and high surface quality
• Eccentric relief eases regrinding and reduces reconditioning cost
• Center cutting for plunging and ramping operations

Application:

• Plunge Milling
• Ramping: Blank
• Slotting: Square End
• Side Milling/Shoulder Milling: Square End
• DIN number 6527
• Tool Dimensions: Flute Configuration: 3
• Helix Angle: 30°
• Corner Style: Corner Chamfer
