Kennametal 5059770 Series UGDE Corner Radius End Mill, 3/4" Dia, 0.0600" Radius, 5 Flute, Solid Carbide, 3/4" Shank Dia

Features:

• Corner Radius End Mill: 3/4" Dia, 3-3/4" LOC, 0.0600" Radius, 5 Flute, Solid Carbide
• 7" OAL, 3/4" Shank Dia, 43.00 deg Helix, AlTiN Finish, Single End, Series UGDE
• Coated fine-grain grade with PVD multilayer (AlTiN). KC643M is a very thin and hard PVD coating particularly suited for cutting steel, cast iron, stainless steel (wet), and titanium (wet). This grade can be used for materials with hardness up to 52 HRC.
• Versatile solid carbide end mill for semi-finishing and finishing of thin walls and deep pockets in titanium, steels, and stainless steels with excellent surface finishes.
• HARVI II Long solid carbide end mills cover side milling operations and dynamic milling.
• HARVI II Long solid carbide end mills feature unequal flute spacing for chatter-free machining at highest feed rates.
• Back taper design for excellent wall straightness.

Application:

• Trochoidal Milling
• Side Milling / Shoulder Milling: Square End
• Tool Dimensions: Flute Configuration: 5
• Corner Style: Corner Radius
• Corner Style: Square End
• Helix Angle: 43°
