Kennametal 1613627 Replaceable-Tip Drill, 16.28 to 16.78 mm Diameter, 52.07 mm Max Depth, 19.05 mm Weldon Flat Shank, 142.88 mm

Features:

• Replaceable-Tip Drill: 16.28 to 16.78 mm Dia, 52.07 mm Max Depth, 19.05 mm Weldon Flat Shank
• Uses KSEM0641 Inserts, Seat Size 1, 142.88 mm OAL, Through Coolant
• The central locking screw mechanism ensures secure clamping of the insert, resulting in process safety and long tool life for both the drill body and the insert
• Internal coolant supply directly to the cutting zone, for extended tool life and efficient chip evacuation

Application:

• Drilling - Through Coolant
• Shank - Cylindrical with Flat and Flange
