Kennametal 1606888 Replaceable-Tip Drill, 23.42 to 23.92 mm Dia, 119.89 mm Max Depth, 25.4 mm Straight-Cylindrical Shank, Seat Size 4, 228.6 mm

Features:

• Replaceable-Tip Drill: 23.42 to 23.92 mm Dia, 119.89 mm Max Depth, 25.4 mm Straight-Cylindrical Shank
• Uses KSEM0922 Inserts, Seat Size 4, 228.6 mm OAL, Through Coolant
• The central locking screw mechanism ensures secure clamping of the insert, resulting in process safety and long tool life for both the drill body and the insert
• Internal coolant supply directly to the cutting zone, for extended tool life and efficient chip evacuation

Application:

• Drilling - Through Coolant
• Shank - Cylindrical Plain ≤h6
