Jomar 100-104-TH 3/4" Ball Valve 2 Piece Full Port Brass Threaded Connection T-Handle 600 WOG

3/4" Ball Valve, 2 Piece, Full Port, Brass, Threaded Connection, T-Handle, 600 WOG

Features:

• Gland Follower and Single O-Ring Stem Design
• Blow-Out Proof Stem
• 100% Leak Tested
• Threaded Connection
• With T-Handle
• Valve Seat Rating - 600 WOG
• Port Size - 3/4"

Part Material:

• Body - Brass C37700
• End Connection - Brass C37700
• Ball - Chrome Plated Brass C37700
• Seat (2) - PTFE
• Stem - Brass C37700
• Packing - PTFE
• Stem O-ring - Buna-N
• Packing Gland - Brass C37700
• Handle - Steel Chrome Plated
• Handle Nut - Steel Chrome Plated
• Lock Washer - Steel Chrome Plated

Certifications/Approvals:

• UL Listed up to 175 PSI
  • MHKZ - Manual valves
  • YRPV - Gas shut-off valves
• UL Listed up to 250 PSI
  • YQNZ - Compressed gas shutoff valves
  • YRBX - Flammable liquid shutoff valves
  • YSDT - LP gas shutoff valves
• CSA Certified
  • CGA 3.16 (125 PSIG)
  • ANSI Z21.15 (.5 PSIG)
  • CGA CR91 (5 PSIG)
  • ASME B16.44 (5 PSIG)
  • ASME B16.33 (125 PSIG)
• FM Approval
• MSS SP-110
• ANSI B1.20.1
