Yamato WG-301 UVUFTB WG301 Auto Pure Water Purifier Benchtop Configuration w/ UV Oxidation Lamp & TOC Monitor, 120V/60Hz

The Auto Pure Lab water system delivers Type 1, 18 MΩ quality water on demand. Water is purified in a staged process consisting of high-purity ion exchange resins to remove dissolved minerals and internal recirculation to maintain purity. At discharge, a final 0.2μm filter removes particulates and bacteria to attain CLSI / ASTM Type 1 water specifications. Additional optional technologies are incorporated depending on model. Resistivity monitor provides feedback of the final water quality.

The Auto Pure system is designed to recirculate through multiple technologies to maintain purity. At designated periods, the system will transition from "Polishing" mode to "Stand By" mode and the recirculation pump, solenoid, and UV (if installed) will be automatically turned off via the PLC Controller. The main screen provides resistivity, TOC (if installed) and the life of the consumables.

The status bars will transition from green, to yellow and to red. The user will still be able to operate the unit during all of these conditions. The unit comes with a built in Leak Detector and when alarmed, it will automatically shut down the system. Alarms and service events are conveniently logged. The unit comes with volumetric dispensing and provides the user six different batch sizes. The user can enter in a numeric value, in mL units, for repeated dispensing. A button is pressed and it will stop automatically once the limit has been reached.

Features:

• 2.5 LPM of 18 MΩ Type 1 reagent water on demand (Performance based upon RO / DI or Distillation Feed (< 20 uS/cm, < 50 ppb of TOC, 0.2 micron filtration))
• Intuitive, user-friendly touch screen interface
• Real time quality monitoring with leak detection
• Compact design - Benchtop type
• Quick change, no tools cartridge design
• Large capacity, low cost consumable cartridges
• Premium quality ion exchange resin
• Low ownership cost
• UV Oxidation Lamp, TOC Monitor included
• Voltage 120 V

Applications:

• Genetics
• DNE Sequencing
• Polymerase Chain Reaction (PCR)

WG Series Configuration:

• Conditioning cartridge
• Polishing cartridge
• UV oxidation
• Ultrafiltration
• 0.2 micron filter

For more information, please see Data Sheet and Manual
