TOA WS-5325H H01US 16 Channel UHF Wireless System - WT-5810(H01) Tuner and WM-5325(H01) Rechargeable Transmitter and WH-4000H Headset Microphone

The WS-5325H includes a wireless transmitter WM-5325, a headset microphone WH-4000H, and a diversity wireless tuner WT-5810. The WM-5325 wireless transmitter has been manufactured for use with a UHF system. Thanks to the PLL-synthesizer system, 64 different operating frequencies are made available. A high output power ensures stable radio signal transmission. The WH-4000H employs an electret condenser microphone element and has been designed for use in speech reinforcement applications. The WT-5810 is a PLL-synthesizer controlled double superhetrodyne diversity tuner designed to be used with a UHF wireless system. It employs a compander noise reduction circuit to minimize the influence of ambient RF noise.

Features:

• Up to 16 selectable frequencies (Up to 16 Simultaneous channels)
• An optimized PLL-synthesizer minimizes the oscillation frequency drift resulting from the ambient temperature or voltage fluctuation
• Audio level control adjusts the microphone sensitivity
• Power/Battery lamps indicate battery consumption to prevent the unit from malfunctioning when the battery level remarkably decreases
• Compact and high reliability
• Transmitter operates on a single AA battery
• Employs a built-in antenna
• Supplied with a headset microphone with unidirectional condenser microphone element

Package includes:

• Wireless transmitter WM-5325 x 1
• Headset microphone WH-4000H x 1
• Diversity wireless tuner WT-5810 x 1
• AC adapter x 1
• Screw driver x 1
• Storage case x 1
• Neck strap x 1

For more information, please see Data Sheet
