Rees 03845-000 Weatherproof Switch

Features:

The following selector switches are hand operated, control circuit devices, rated 'Heavy Duty' normally for use with electromagnetic equipment. The die-cast zinc body, is painted with a dry powder paint. The die-cast zinc wing lever is either painted black or nickel plated. Each terminal will accept (2) #14 AWG stranded wires. The switches are supplied with all mounting hardware and a solid neoprene rubber gasket which provides an oil tight seal upon installation. The mechanical life of these devices is 500,000 operations. These switches can be found on a wide variety of machinery. Their rugged construction and long term reliability make these switches extremely well suited to function within various industrial conditions.

Electrical Ratings:

• See attached Chart
• Listed under UL 508 - File # E 58589;
• Certified under CSA C22.2 - File # LR 3648

Environmental Temperature Range:

• Operating: +32°F to +131°F (0°C to +55°C)
• Storage: -40°F to +185°F (-40°C to +85°C)
• Note: Operating temperatures at 0°C are based on the absence of freezing moisture and liquids.
