Owon OWH9830 Three-Phase Digital Power Meter 1000V / 20A, 3-Phase 3-Wire / 4-Wire, Harmonics Analysis

Features

• Two-channel design CH1 (rear panel): AC input - Supports 3-600V / 0-20A RMS, with an accuracy of ±0.5% CH2 (front panel): AC/DC input - Supports 0-1000V / 0-20A, with an accuracy of ±0.5%
• Supports single-phase and three-phase measurements, with 16 common parameters available for measurement
• Harmonic measurement and analysis functionality, capable of analyzing up to 63rd harmonics
• Combination of input and output power information for both channels, with automatic calculation of conversion efficiency
• Trend waveform display, providing visual representation of dynamic parameter changes for easy debugging and analysis
• 3.95" TFT LCD screen with clear, graphical display of multiple parameters, offering intuitive operation
• Standard RS232 interfaces for remote monitoring and data logging, compatible with SCPI and Modbus protocols
