Overview
The ODP8000 Series Programmable DC Power Supply delivers excellent output precision, with a minimum resolution of 1mV / 1mA. It features low ripple and noise performance (≤1mVrms / 5mVpp), along with outstanding setting and readback accuracy, ensuring clean and stable power output for precision-demanding applications.
Automatic Constant Voltage / Constant Current Switching
The ODP8000 power supply normally runs in Constant Voltage (CV) mode, keeping voltage steady while current changes with the load. If a short circuit or overload causes an overcurrent condition, the hardware quickly switches to Constant Current (CC) mode, limiting current to a safe level and lowering voltage. This fast hardware switching happens in microseconds without software control, ensuring safe and reliable operation.
Innovative Data Logger Function
Built-in data logger supports both manual and automatic recording, with flexible settings for interval time, number of points, and channels. It can capture real-time voltage, current, and power data, displaying them visually as tables or waveforms.
Features:
- 3-channel independent adjustable output channels; CH1 and CH2 support series/parallel connection
- CH1/CH2: 5A / 90W constant power; CH3: 3A / 24W constant power
- 5-digit voltage/current display with 1mV / 1mA resolution
- Low ripple and noise: ≤1mVrms / 5mVpp
- OVP, OCP, OTP, OPP protection for safety and reliability
- Intelligent CV/CC mode switching
- Supports 100 sets of timed output sequences
- Remote voltage sensing supported
- Built-in data logger for displaying voltage, current, and power in table or waveform format
- System parameter save/recall, with expandable data storage
- 4.3-inch (480*272) IPS screen for sharp and vivid display
- Supports USB 2.0, RS232, and LAN communication interfaces
Package includes:
- ODP8353 Programmable DC Power Supply
- Power Cord
- Quick Guide
- USB Cable
- Fuse
For more information, please see Specifications
