NOVUS 8801232500 NP640 Oil-Filled Pressure Transmitter 1/2 BSP, DIN, IP65, 4-20MA, 0-250 bar (3625.9 Psi)
- Specification
- Overview
- Accessories
- Customers Also Bought
- Your Recently Viewed Items
- Reviews
- $135.00 / Each
- Brand:NOVUS
- Part #:8801232500
- Model #:NP640
'%3e%3cpath%20d='M30%205.625C36.4647%205.625%2042.6645%208.19307%2047.2357%2012.7643C51.8069%2017.3355%2054.375%2023.5353%2054.375%2030C54.375%2036.4647%2051.8069%2042.6645%2047.2357%2047.2357C42.6645%2051.8069%2036.4647%2054.375%2030%2054.375C23.5353%2054.375%2017.3355%2051.8069%2012.7643%2047.2357C8.19307%2042.6645%205.625%2036.4647%205.625%2030C5.625%2023.5353%208.19307%2017.3355%2012.7643%2012.7643C17.3355%208.19307%2023.5353%205.625%2030%205.625ZM30%2060C37.9565%2060%2045.5871%2056.8393%2051.2132%2051.2132C56.8393%2045.5871%2060%2037.9565%2060%2030C60%2022.0435%2056.8393%2014.4129%2051.2132%208.7868C45.5871%203.16071%2037.9565%200%2030%200C22.0435%200%2014.4129%203.16071%208.7868%208.7868C3.16071%2014.4129%200%2022.0435%200%2030C0%2037.9565%203.16071%2045.5871%208.7868%2051.2132C14.4129%2056.8393%2022.0435%2060%2030%2060ZM43.2422%2024.4922C44.3438%2023.3906%2044.3438%2021.6094%2043.2422%2020.5195C42.1406%2019.4297%2040.3594%2019.418%2039.2695%2020.5195L26.2617%2033.5273L20.7539%2028.0195C19.6523%2026.918%2017.8711%2026.918%2016.7812%2028.0195C15.6914%2029.1211%2015.6797%2030.9023%2016.7812%2031.9922L24.2812%2039.4922C25.3828%2040.5938%2027.1641%2040.5938%2028.2539%2039.4922L43.2422%2024.4922Z'%20fill='%2300A046'/%3e%3ccircle%20cx='30.5'%20cy='29.5'%20r='20.5'%20fill='white'/%3e%3cpath%20d='M21.8175%2037H18.7395L13.5915%2029.206V37H10.5135V24.364H13.5915L18.7395%2032.194V24.364H21.8175V37ZM27.1266%2026.83V29.386H31.2486V31.762H27.1266V34.534H31.7886V37H24.0486V24.364H31.7886V26.83H27.1266ZM51.1749%2024.364L47.8809%2037H44.1549L42.1389%2028.684L40.0509%2037H36.3249L33.1209%2024.364H36.4149L38.2329%2033.562L40.4829%2024.364H43.8669L46.0269%2033.562L47.8629%2024.364H51.1749Z'%20fill='%2300A046'/%3e%3c/g%3e%3cdefs%3e%3cclipPath%20id='clip0_10639_3631'%3e%3crect%20width='60'%20height='60'%20fill='white'/%3e%3c/clipPath%3e%3c/defs%3e%3c/svg%3e)
- $135.00
Special Order!
Item is made to order, non returnable and non cancelable.
Overview
NOVUS 8801232500 NP640 Oil-Filled Pressure Transmitter 1/2 BSP, DIN, IP65, 4-20MA, 0-250 bar (3625.9 Psi) is a pressure transmitter that measures relative pressure and converts it into an output signal for monitoring or control.
This NP640 pressure transmitter is ideal for instrumentation technicians and controls engineers who require configurable pressure measurement for applications like pressurized food or beverage lines and cooling water monitoring.
The NP640 is an oil-filled relative pressure transmitter with an adjustable measuring range up to 0-250 bar, featuring a 1/2 BSP process connection, DIN connector, 4-20mA output signal, and IP65 protection rating.
Range setting and factory calibration are handled with the TxConfig-DIN43650 configuration application. The unit mounts on its 1/2 BSP process connection, and the DIN 43650 connector takes care of the electrical connection.
- Oil-filled relative pressure transmitter
- Model: NP640
- Measuring range: 0-250 bar (3625.9 Psi)
- Process connection: 1/2 BSP
- Electrical connection: DIN 43650 connector
- Output signal: 4-20mA
- Protection rating: IP65
- Configurable via TxConfig-DIN43650 software
FAQ about the NOVUS 8801232500 NP640 oil-filled pressure transmitter
What is the measuring range of this NP640 transmitter?
The measuring range is 0 to 250 bar (3625.9 Psi).
Which process connection does the transmitter use?
It uses a 1/2 BSP threaded process connection.
How is this pressure transmitter configured?
Configuration is done using the TxConfig-DIN43650 application.
You can find more transmitters and accessories in the Transmitters collection.
