Kennametal 5689994 Series T686 Spiral Flute Tap, M5 x 0.08, Metric Coarse, 3 Flute, Modified Bottoming Chamfer, 6H Class of Fit, Cobalt

Features:

• Spiral Flute Tap: M5x0.08, Metric Coarse, 3 Flute, Modified Bottoming Chamfer, 6H Class of Fit, Cobalt, Multi-layer Finish
• 12.00 mm Thread Length, 70.00 mm OAL, Right Hand Flute, Right Hand Thread, H5, Series T686
• High-vanadium HSS-E substrate with a coating consists of low-friction CrC/C over wear-resistant TiN base layer. Use for tapping stainless steel and non-ferrous materials.
• KSMN34 TiN + CrC/C for aluminum.

Application:

• Tapping: Blind Hole
• Class of Fit: 6H
• Chamfer Form C (2 - 3)
• 38618
• Manufacturer's Specs: M
• Flood Coolant: Tapping
• Tapping Helix Angle: 25°
• DIN Number ANSI
