GF Piping Systems 3-8058-1 Signal Converter, One Channel for 8900

The Signet i-Go 8058 Signal Converter accepts any 4 to 20 mA signal and converts it into the Signet digital (S3 L) format, the serial data format used by the Signet 8900, 9900 and 9950 instruments and Profibus Concentrator. When used with the 8900 MultiParameter Controller, 9900 or 9950 Transmitter or the Profibus Concentrator, the measurement type and operating range are defined in the setup menu. When used with level, temperature and pressure ProcessPro transmitters, the 8058 is confi gured at the factory to the user's specifi cations. The wire-mount single-channel version is easily mounted anywhere in the interconnecting wiring between the sensor and the instrument.

Features:

• Connects with level, temperature, pressure and Multi-Parameter Signet instruments
• Single 4 to 20 mA sensor input
• Connects additional measurement parameters to Signet Multi-Parameter instruments
• In-line wire

Applications:

• Dissolved Oxygen Monitoring and Control in Wastewater
• Chlorine Dioxide for Disinfection
• Specific Ion
• BOD
• TOC
• Alkalinity
• Ozone Monitoring
• Conductivity
• Chlorine Injection Control
• Tank Level Monitoring
