FRC FCA800-M10 Focus Low Profile Lamphead, 1000W, 120V, Brow, Contour Mount

Don't waste precious light

The high intensity FOCUS lamphead uses a uniquely designed patented reflector to eliminate wasted light. It is designed to focus 100% of the light produced into the area where it is needed. Built tough, the compact design allows it to be mounted in places that traditional lighting fixtures do not fit.

FOCUS low profile lampheads were the first lampheads to introduce the concept of redirecting light with fifty parabolic curved and aimed surfaces. The innovative design directs light where it is needed. The low profile of the classic FOCUS offers mounting options that many other lights cannot.

Fire Research Focus model with contour roof mount. The mounting brackets attach to the bottom of the lamphead and be machined to conform to the roof radius. Wiring extends from a weatherproof strain relief at the rear of the lamphead.

The lamphead has one (1) quartz halogen bulb. The bulb shall be accessible through the front. The lamphead directs 50 percent of the light onto the action area while providing 50 percent to illuminate the working area. The lamphead incorporates heat-dissipating fins and be no more than 5-1/4" deep by 3-3/8" high by 15" wide. Lamphead and brackets are powder coated white. The floodlight is UL listed as scene lights for fire service use.
