Altelix NP141105TVMP NP Series Light Ivory 14x11x5 Vented Polycarbonate + ABS RF Transparent Outdoor WiFi Enclosure with No-Drill PVC Mounting Plate

The Altelix NP141105TVMP Vented Polycarbonate + ABS NEMA Weatherproof Enclosure is ideal for protecting equipment from harsh environments and tampering. Equipment designed for indoor use can now be located outside.

PC+ABS Polycarbonate / ABS Blend for Extreme Durability

These enclosures are molded out of UV resistant PC+ABS, a high tech thermoplastic blend of polycarbonate and ABS which combines the best qualities of both into a single material. PC+ABS enclosures are superior to ABS enclosures because they maintain high toughness, durability and dimensional stability even at extreme cold and hot temperatures.

Construction and Features

This enclosure is IP24 rated and features a fully gasketed door to protect from dust and water ingress. The door features reinforced hinges, dual latches and a tamper-proof locking screw with key to secure the enclosure. There is also a provision for padlock use. This enclosure can be easily drilled and modified by the installer to suit unique site requirements.

No-Drill Non-Metallic Equipment Plate

This configuration consists of the PC+ABS enclosure with hinged lid and a 1/4" thick non-metallic PVC plate for mounting and securing equipment. Due to the "No-Drill" design of this PVC plate, mounting radios and other equipment can be done simply by using self-tapping screws.

RF Transparent Design

The NP141105TVMP is ideal for WiFi applications. The non-metallic design of both the enclosure and equipment mounting plate will not interfere with the radio's operation. In addition, mounting radios to PVC equipment mounting plate can be done simply by using self-tapping screws. The size of this enclosure will fit a wide range of popular wireless points on the market.

Ventilation

This enclosure features two 3.0 inch air vents. Rain shields help prevent rain water from entering the enclosure.

Mounting

The enclosure can be wall mounted using the included wall anchors.

Complete with Cable Grommets and Wire Management Accessories

This enclosure includes an assortment of cable grommets that can be installed in the knock-out holes for a weather resistant seal. The included accessory kit contains wall anchors, zip ties, wire management loops, grounding plate and ground wire, door locking key and more.

Features:

• Dual 3" Vents with Rain Shields to Expel Heat
• ABS + Polycarbonate Enclosure
• Features a No-Drill PVC Non-Metallic Equipment Mounting Plate - Mount your equipment securely without the need for drilling!
• Black Enclosures Now Include a Black PVC Equipment Mounting Plate
• Gasketed Lid with Tamper-Proof Locking Screw
• Dual Door Latches
• NEMA Type 3R, 3RX / IP24 Rated
• Includes Wall Mount Hardware and Cable Grommets

Applications:

• WiFi Access Points and Routers
• SCADA Remote Terminal Unit
• Security and Surveillance Systems
• Outdoor Use of Indoor Equipment
• Protection Against Theft or Damage
• Warehouses and Public Areas
• Concealment of Equipment
