Flowline AV46-S243-A-B-C-D-E Float-Point with Compact Junction Box 316 SS, 4-Float, 2" NPT

The general purpose level float switch package provides reliable, multi-point liquid level detection of relatively clean liquids such as water, diluted chemicals and light weight oils up to 8' (2.44m) with 1-5 reed switch outputs and a compact junction box for integral wiring termination. The stainless steel level float switch is selected for high temperature or pressure process tank level applications.

Features:

• Multi-point float level switch solution for high temp and pressure
• 60VA dry contacts connect directly to a PLC or relay controller
• Rugged 316 stainless steel float, guide and mounting plug
• PP enclosure rated NEMA 4X with swivel base for conduit alignment
• Assembled to your guide length and switch set point dimensions
