Overview


Key Features:

  • This easy-to-use binocular student microscope with built-in camera is perfect for classrooms.
  • Stream and capture live images to your computer with this binocular compound microscope with integrated 1.3MP camera.
  • 40X to 2000X magnification with four objective lenses and two sets of eyepieces.
  • Daylight-balanced, low-heat LED light-source provides bright transmitted illumination for viewing and imaging specimens.
  • Double-layer mechanical stage and coaxial coarse and fine focus for easy, precise adjustments.
  • Includes 100 blank slides and cover slips.

OMAX Digital MicroscopyOMAX Digital Microscopes integrate advanced digital-imaging with precision optical-microscopy. Digital integration promotes uniformity and presents a simplified method for setting up and using microscopes.
OMAX provides a large range of solutions for education, research, and industry. Building on industry standards, we provide a full range of accessories to suit your needs.

The OMAX MD82ES10 provides all of the essential functionality needed in the classroom or lab for common microscopy applications. The digitally-integrated head offers an amazing amount of flexibility, allowing for simultaneous viewing through the eyepieces and on a computer. A professional software platform for Windows is provided to capture photos and video, with editing tools to optimize images, and aid in analysis. The imaging process is further enhanced by achromatic color-corrected optics which provide sharp, clear images over a wide range of magnifications. Coaxial focus and mechanical stage movements provide precision and ease.

The MD82E series microscope uses a binocular viewing head. To customize the microscope to your viewing comfort, the eyepiece spacing can be easily adjusted using a simple sliding mechanism. Diopters are available on each ocular tube to fine-tune the eyepieces, and the ocular tubes are angled at 45° to accommodate sitting or standing. Various eyepieces can be used to increase the overall optical magnification without changing the camera's magnification.

The objective turret provides instant access to 4 magnification levels to easily focus in on minute details from 40X to 1000X. For traditional viewing, additional 20X eyepieces extend the maximum magnification to 2000X, and provide 8 distinct levels of magnification. The high-quality lenses are achromatically corrected to improve resolution and color accuracy.

The 2-layer mechanical stage provides smooth and precise movement for examination of specimen slides. The stage's low-position controls are conveniently placed near the coaxial focus knobs for a streamlined workflow. Variable-intensity LED lighting offers bright, daylight-balanced illumination to produce high-contrast, color-correct images.

100 blank slides and cover slips are included to get things started. These pre-cleaned slides can be used for dry-mount or wet-mount with the included coverslips.

Specifications

Optical SystemFinite-conjugate
Tube Length160mm
HeadDigital-integrated binocular, 45° incline, 360° rotatable
Interpupillary AdjustmentSliding, 55-75mm
Ocular Diameter23mm
Eyepieces10X, 20X
Objective Turretquadruple
Focusing Systemcoaxial coarse and fine focus
Stage2-layer mechanical
Stage Dimensions125mm x 115mm
Stage X-Y Travel Range70mm x 30mm
Specimen HoldersSlide caliper
Transmitted Illumination1W LED, variable intensity
CondenserAbbe condenser with iris diaphragm, NA1.25
Sub-stage Condenser-holderRack-and-pinion
Power100-240VAC 50/60Hz wide-band
Dimensions9-1/16" x 7-1/8" x 13" (23cm x 18cm x 33cm)

Objective Lenses

MagnificationCorrectionsNAImmersion MediumCover-glass Thickness
4Xachromatic0.10none0.17mm
10Xachromatic0.25none0.17mm
40Xachromatic0.65none0.17mm
100Xachromatic1.25oil0.17mm

Camera Specifications
Sensor TypeCMOS
Sensor Optical Format1/2.5"
Active Pixels1.3M (1280 x 1024)
Shutterelectronic rolling shutter
Capture Resolution and Maximum Framerate6fps @ 1280x1024
10fps @ 1024x768
ConnectivityUSB 2.0
Power5VDC over USB

Software

OS RequirementsWindows (32/64 bit) XP/Vista/7/8/10
Hardware RequirementsIntel Core2 2.8GHz or comparable processor, 2GB RAM, USB2.0 port
Features
Windows Version
Live video preview
Captures still images and video
Exposure and white-balance controls
Image processing
Measurement tools, including lines, arcs, polygons

Packing List:

  • Digital binocular microscope
  • 4 objectives: 4X, 10X, 40X, 100X
  • A pair of eyepieces WF10X
  • A pair of eyepieces WF20X
  • A bottle of Immersion oil
  • AC adapter (US and Canada standard)
  • Dust cover
  • Color filters
  • CD (camera driver and software)
  • USB2.0 cable
  • 100 blank slides and cover slips
  • For ages 14+
