Brigade Electronics 4982A Select Monitor 7" LCD 4 Inputs Audio

Brigade Monitors

In-cab monitors are a vital part of the safety process, giving the driver essential information about the vehicle's surroundings. Brigade's compact 5" screen LCD monitors are suitable for smaller commercial vehicles or where cab space is limited. With single-to-multiple camera inputs and auto-triggers, Brigade monitors will work on any application in any industry, regardless of the amount of camera views connected.

The Benefits of using Monitor Systems:

• Eliminates Blind Spots -  Calibrated cameras capture all of the surrounding areas including the blind spots of the vehicle or machine
• Real-time Views - Live pictures of the vehicle or machine's surrounding area fed to the monitor without latency (time lag)
• Ultra-wide Cameras - One camera covers one full side of the vehicle with a viewing angle of over 180°
• Recordable - Record a high definition image to an external MDR of all the individual camera feeds

Features:

• Quad view monitor with multiple views.
• Configurable view options with double / triple / quad / 360 / ‘H' & Picture In Picture support.
• Configurable split option for additional camera usage with Backeye 360 systems.
• Scalable and Picture In Picture placement options.
• Configurable trigger input functions.
• High Quality Digital LCD with LED backlight.
• Low Reflection TFT LCD (Anti Glare Coating).
• Integrated light sensor for backlight dimming.
• Illuminated touch keypad.
• Keypad disable/lock Via OSD Menu.
• Integrated large speaker.
• Automatic detection of PAL or NTSC Signal.
• 10 x On Screen Display (OSD) languages: (English, French, German, Spanish, Turkish, Italian, Dutch, Portuguese, Russian, Polish).
• Configurable trigger off delay (0-20 sec.).
• Configurable Auto Scan delay (0-20 sec.).
• 2 x Variations of electronic on screen markers.
• Compatible with Remote Control VBV-7X0DM-RC.

Technical Specifications:

• Operating Voltage: 12 / 24 Vdc
• Current Consumption: ≤ 2.23A at 12Vdc
• Power Consumption: ≤ 27W at 12Vdc
• TV System: PAL / NTSC
• Display Size: 7.0" (diagonal)
• Resolution: 800 x (RGB) x 480
• Contrast Ratio: 500:1
• Brightness: 400 cd/m²
• Display Viewing Angle: 50(T), 70(B), 70(L), 70(R)
• Number of Triggers Inputs: 5
• Mirror/Normal via OSD Menu: All Channels
• Number of Video Inputs: 4 (VBV connectors - 4 pins)
• Shutter camera support: None
• Tilt camera support: None
• Speaker Rating: 8Ω at 2 Watt
• Video Input Impedance: 1.0 Vp-p / 75Ω
• Monitor Weight: Approx. 550 Grams
• Monitor Dimensions: (Without Sunshield) 195.5 mm (W) x 25.5 mm (D) x 117.5 mm (H)
• Power / Trigger Cable Thickness: 18 AWG
• Cable Length:
• - Monitor Pigtail: 900 ± 30mm
• - Cable Adapter: 1000 ± 80mm
• Casing Material: ABS Plastic
• Finish / Color: Soft Touch Black

Environmental Specifications:

• Shock Rating: 100 G
• Vibration Rating: 4 G (All 3 axis each 32hr random)
• Connector IP Rating: IP40
• Monitor IP Rating: IP30
• Operating Temperature: -30° to +70°C
• Storage Temperature: -40° to +85°C

Approved Standards:

• CE - (EN 61000-6-2:2005 + AC:2005) / (EN 61000-6-3:2007 + A1:2011 + AC:2012)
• FCC - (47 CFR Part 15 Subpart B)
• IC - (ICES-003:2016, Issue 6)
• E-Mark - (UNECE regulation R10 revision 5)
• Elements of ISO 16750
• HALT
• RoHS
• WEEE

Package Includes:

• 1x VBV-770FM-M - Monitor Only
• 1x VBV-770FM-CA - Cable Adapter
• 1x VBV-770M-SS - Sunshield
• 1x VBV-770FM-IG - Installation Guide
• 1x BMM-015 - Short Arm Bracket
