AmScope DC20000S Scientific sCMOS 20MP USB 3.0 C-Mount Microscope Camera

  • Overview
  • Customers Also Bought
  • Your Recently Viewed Items
  • Reviews
AmScope DC20000S Scientific sCMOS 20MP USB 3.0 C-Mount Microscope Camera
Click to zoom
Factory Warranty
Warranty
Condition
Condition: new
Safe Checkout
Fully secured
Money back Guaranty
100% satisfaction

Overview

AmScope DC Series Scientific sCMOS 20MP USB 3.0 C-Mount Microscope Camera

  • SONY Exmor R sCMOS color USB 3.0 camera.
  • Low signal/noise ratio.
  • Back-illuminated sCMOS sensor.
  • High resolutions of 5440 x 3648 @15 fps, 2736 x 1824 @50 fps, and 1824 x 1246 @60 fps
  • Perfect color-reproduction capability.

The different USB-3 sCMOS cameras with ImageFocus capture and analysis software are the perfect solution for today's educational, laboratory, and industrial microscopy needs. The cameras are suitable for Life Science and Materials Science microscopes as well as stereo microscopes

sCMEX USB-3 camera with Scientific sCMOS sensor

The sCsCMEX-20 camera is equipped with a scientific grade back-illuminated sCMOS sensor with 16 bits grayscale conversion and outstanding 36 bits color rendering. Suitable for brightfield, darkfield, and fluorescence. The sCMEX cameras are equipped with a USB-3 data interface and supplied with ImageFocus Alpha software

Besides capturing images and videos, the software allows measurements of still and live images and annotations on captured images. Compatible with Windows 8.1/10/11, both 32 and 64 bits configurations. Also compatible with Mac OS (image capturing only). PC requirements: Intel Core2 2.8 GHz or higher or equivalent, 2 GB memory, USB-3 port, 17-inch display

SPECIFICATIONS

Sensor
SONY Exmor R sCMOS

Sensor Size (inches)
1" 2.4 x 2.4

Number of Pixels
20MP

Resolutions
5440 x 3648 @15 fps
2736 x 1824 @50 fps
1824 x 1246 @60 fps

Exposure Time
0.264 ~ 15000 ms

Grayscale Conversion
16 bits

Dynamic Range (db)
66.3

S/N Ratio (db)
41.74

Color Rendering
36 bits

Sensitivity V/lux-sec
0.21

Scan mode
Progressive, rolling shutter

Filter
RGB

Mount
C-mount

ADC
16 bits

Color depth
36 bits

Exposure
Automatic or manual

White balance
Automatic/manual

Data interface
USB 3.0

Operation
0 - 60° C, 45-85 % humidity

Storage temperature
-20 to 70° Celsius

Packing Slip

  • 1x objective with C-mount (for sCMEX-20)
  • USB 3.0 cable
  • 30 and 30.5mm adapters for stereo microscopes
  • 76 x 24 mm calibration slide (1mm/100)
  • CD ROM with Image Focus Alpha software

Software
Supplied with ImageFocus Alpha, image and video capturing and measuring software
For Win 7/ 8/ 10 (32 and 64-bit configurations)
PC requirements: Compatible with Intel Core 2, 2.8 GHz or higher, 2GB, USB-3 high speed, 17-inch display
A Mac OS Light software version is also supplied, image capturing only
